Swan-Neck street/platform lamps - black - 4mm scale - DCC concepts

Swan-Neck street/platform lamps - black - 4mm scale - DCC concepts

Pack Contents 6x 4mm scale street/platform lamps with 200mm connection wires
2x 4mm scale wall lamps with 200mm connection wires
8x Resistor boards – suitable for connection to regulated DC power 6-12V

Installation Advice Drill the mounting hole using a 2mm drill. Carefully thread the fine wires into the hole, then insert the lamp mounting tube.
The longer of the 2 wires is the + lead. Connect your power supply to the resistor board and then try the lamp with each of the resistor values to select your preferred light level.
Alternatively, if a different level is wanted, you may also use any other value 1/4 watt resistor as long as it is larger than 1k Ohms.
Connect several lamps (up to 6) to one resistor board if you wish.
Power supply Any regulated DC power supply between 6 and 15 volts will be suitable. (To save you any additional cost, you may find one in your bottom drawer, for example an unused mobile phone charger or any similar power supply).
